Stereo Tool

Oops, that's a bug. Will put it on the todo list.

Windows 32 bit (note: Almost identical to 004, but the stand alone version was missing and I fixed a few minor things):
Windows stand alone: http://www.stereotool.com/download/ster ... 52-005.exe
Winamp DSP: http://www.stereotool.com/download/dsp_ ... 52-005.exe

CHANGES:
- Display FM lowpass frequency at bottom when FM output is used.
- Show warning when PNR is disabled due to changed settings.

TODO:
- Band coupling settings don't work if Band Coupling slider in main Multiband window is set to 0%.
- ABDP: Use Dirty Mids/Highs on final steps but not on preclipping steps. Might make sound more consistent and avoid more distortion. Also try to remove audio from outside the filtering range. (Not that easy). -> DONE, a bit different from what I planned but I found another way of doing this. Result: Slightly louder, 0.5 dB more highs! And probably less pumping due to highs.
- Declipper result is very bad if PNR is used before it.
- PNR can also be done AFTER declipping.
- Split filters in Restoration / Processing, and make them saveable separately.

PREVIOUS:
- Added Multiband compressor Band Coupling matrix. You can use this to overrule the standard band coupling settings. Only available in Extreme Tweaker mode, awaiting responses to see how useful it it (if it is useful I'll move it to Expert mode).
- Advanced Clipper: Advanced Bass Distortion Protection (ABDP): Drop in output when strongly clipping around 2600-4000 Hz is reduced.
- Advanced Clipper: ABDP: "Smooth Slide" slider added to make transition between deep bass (clipped) and less deep bass smoother. There used to be a drop upto the 2nd configured bass frequency, with this switch enabled the drop is smoothed (maximum at 1st configured bass freq, gone at 2nd). Result: Warmer, more open, less 'restrained' sound. But probably also a bit more intermodulation distortion. (which might be fixable by changing the frequencies a bit). (*)
- Added PNR Noise & Hum
- PNR analysis data is saved now

No but you can use the 32 bit version for now.

Advanced Clipper -> Advanced Bass Distortion Protection -> 4th row. I see it's called 'Smooth slope', sorry for the confusion...

Then how Coupling will be turned off ? If it will work even with 0% ?
Some button or what ?
I saw they are different % when i set to 100 and then to 0 and again if i set it to 100 and then to 0 - again different % on some sliders ?!

Edit: When Auto is selected , Norm is greyed out(disabled) but still affect the audio if enabled/disabled.

Hi to the group... I think i found a bug... when pnr is on decliper goes crazy....more photos in a bit..

_________________
Very proud user of Stereo Tool since 2010. Thanks Hans.

My radio station
http://amradio.ddns.net

When Multiband selected , all other menus on the left are gone/disappear . Now i must press "Processing" to turn them on screen.
Was not like that

Even in Extreme Tweaker, I do not see that panel in Advanced Clipper using beta 4. I do see the coupling screen, so I'm sure I have the right version, despite it still saying 7.51 in the title bar. I also reinstalled, to be sure I was using the correct version. The panels I can see under Advanced Clipper are:

Pre-limiter
Bass
Highs
CPU
Distortion
Sound
Stokkemask FM

Maybe it didn't make it into the first standalone beta 4?

Click DIstortion and see on 4th row right side...

Excellent. Thank you!
